C65
Expandable
Can be paralleled up to 30MW of power
Specifications
Rating:
65 kW
Electrical Efficiency LHV:
28%
Combined Heat And Power Efficiency::
Up to 90%
Voltage:
400-480 VAC
Frequency:
50/60 Hz
Electrical Service:
3-Phase, 4-Wire Wye
Width:
0.76 m (30 in)
Depth:
1.95 m (77 in)
Height:
1.91 m (75 in)
Weight:
Grid Connect - 758 kg (1,671 lb); Dual Mode - 1,121 kg (2,471 lb)
Net Heat Rate LHV:
12.4 MJ/kWh (11,800 BTU/kWh)
Exhaust Temperature:
309ºC (588ºF)
Exhaust Gas Flow:
0.49 kg/s (1.08 lbm/s)
Compatible Fuels:
Natural Gas, Liquid Fuels (Kerosene, Aviation Fuels, Ultra Low Sulfur Diesel #2), Biogas (Landfill, Digester), Associated Gas, Sour Gas, Propane Gas
Data Sheets
C65 Digester Gas C65 High Pressure Natural Gas C65 High Pressure Sour Natural Gas C65 ICHP Natural Gas CARB C65 ICHP Natural Gas C65 Landfill Gas C65 Liquid Petroleum Gas C65 ICHP Liquid Petroleum GasNotes
- Nominal full power performance at ISO conditions: 59˚F, 14.696 psia, 60% RH
- Height dimensions are to the roofline. Exhaust outlet can extend up to 7 inches above the roofline.
- Specifications based on high pressure natural gas systems. Values may vary with other fuel types.
Specifications are not warrantied and are subject to change without notice.
